FS fully automatic sorting high-precision cross cutting machine

This cross cutting machine is suitable for cutting large roll packaging materials of different types such as paper, film, paper plastic composite, cloth, leather, etc.


Practical videos
Scope of application
This cross cutting machine is suitable for cutting large roll packaging materials of different types such as paper, film, paper plastic composite, cloth, leather, etc.
Performance characteristics
This cross cutting machine uses a servo motor (or stepper motor) to control fixed length cutting. The transmission system adopts centralized control such as pneumatic and photoelectric sensors. This machine integrates light, electricity, and gas, with simple operation, high cutting accuracy, mechanical stability, and low noise. (Pneumatic feeding optional) Motor variable frequency speed regulation, automatic counting, alarm stop, magnetic powder or friction plate manual tension adjustment function.
Technical parameter
Model FS-800B FS-1100B FS-1300B FS-1600B
Raw material diameter(≤) ¢800mm ¢800mm ¢800mm ¢800mm
Cutting width(≤) 800mm 1100mm 1300mm 1600mm
Cutting length 20-1200mm 20-1200mm 20-1200mm 20-1200mm
Fixed length accuracy ±0.2mm ±0.2mm ±0.2mm ±0.2mm
speed 10-140times/min 10-140times/min 10-140times/min 10-140times/min
Whole machine power 4KW 4KW 5.5KW 5.5KW
weight 1500kg 1700kg 2100kg 2300kg
External dimensions 3000×1400×1200(mm) 3000×1500×1200(mm) 3000×1700×1200(mm) 3000×1900×1200(mm)
